Ripple and noise
≤1% peak value(100mVp-p
standard)
Overload Protection
110%-150%
Hiccup mode
auto-recovery
Overvoltage Protection
110%-140%
Hiccup mode; auto-recovery
Short Circuit Protection
Output terminal circuit
Hiccup mode
auto-recovery
Working Temperature/Humility
-30C~+70C/20-90%RH
Without consendation
Storage Temperature/Humility
-40C~85C/10-95%RH
Without consendation
Safety Standard
UL62368-1
TUV BS EN/EN62368-1
BS CNS14336-1
EAC TP TC004 EN/EN61558-1/-2-16
CCC GB4931.1
BSMI
Withstand Voltage
Input to output:4KVAC Input to ground:2KVAC Output to ground:1.25KVAC
EMC Emission
EN55032
EN55014
EN61000-3-2
GB/T9254
BSMI CNS13438
FCC ClassB
Insulation Impedance
I/P-O/P
I/P-FG
O/P-FG:100m Ohm/500VDC
{"json":"[{\"index\":\"0\",\"tran_value\":[],\"tran_label\":\"Basic data\"},{\"index\":\"1\",\"tran_label\":\"Color\",\"tran_value\":[\"Primary\"]},{\"index\":\"3\",\"tran_label\":\"Rated Power\",\"tran_value\":[\"75W\"]},{\"index\":\"11\",\"tran_value\":[],\"tran_label\":\"Input\"},{\"index\":\"4\",\"tran_label\":\"Input Voltage\",\"tran_value\":[\"AC85V-264V\"]},{\"index\":\"5\",\"tran_value\":[\"47-63Hz\"],\"tran_label\":\"Input Frequency\"},{\"index\":\"6\",\"tran_value\":[\"＜0.75mA\"],\"tran_label\":\"Leakage Current\"},{\"index\":\"13\",\"tran_value\":[],\"tran_label\":\"Output\"},{\"index\":\"14\",\"tran_value\":[\"+-10%\"],\"tran_label\":\"Voltage Adjustment Range\"},{\"index\":\"15\",\"tran_value\":[\"1%\"],\"tran_label\":\"Out Stability\"},{\"index\":\"10\",\"tran_value\":[\"≤1% peak value(100mVp-p\",\"standard)\"],\"tran_label\":\"Ripple and noise\"},{\"index\":\"17\",\"tran_value\":[\"1% typical value\"],\"tran_label\":\"Loading Adjustment Rate\"},{\"index\":\"18\",\"tran_value\":[],\"tran_label\":\"Protection\"},{\"index\":\"19\",\"tran_value\":[\"110%-150%\",\"Hiccup mode\",\"auto-recovery\"],\"tran_label\":\"Overload Protection\"},{\"index\":\"20\",\"tran_value\":[\"110%-140%\",\"Hiccup mode; auto-recovery\"],\"tran_label\":\"Overvoltage Protection\"},{\"index\":\"21\",\"tran_value\":[\"Output terminal circuit\",\"Hiccup mode\",\"auto-recovery\"],\"tran_label\":\"Short Circuit Protection\"},{\"index\":\"22\",\"tran_value\":[\"Air cooling\"],\"tran_label\":\"Cooling Method\"},{\"index\":\"23\",\"tran_value\":[],\"tran_label\":\"Environment\"},{\"index\":\"24\",\"tran_value\":[\"-30C~+70C/20-90%RH\",\"Without consendation\"],\"tran_label\":\"Working Temperature/Humility\"},{\"index\":\"25\",\"tran_value\":[\"-40C~85C/10-95%RH\",\"Without consendation\"],\"tran_label\":\"Storage Temperature/Humility\"},{\"index\":27,\"tran_value\":[],\"tran_label\":\"\"},{\"index\":\"26\",\"tran_value\":[\"CE\",\"RoHS\"],\"tran_label\":\"Certification\"},{\"index\":\"27\",\"tran_value\":[\"-40°C to +85°C\"],\"tran_label\":\"Operating Temperature\"},{\"index\":\"16\",\"tran_label\":\"Safety&EMC\",\"tran_value\":[\"Natural air cooling\"]},{\"index\":\"2\",\"tran_value\":[\"UL62368-1\",\"TUV BS EN/EN62368-1\",\"BS CNS14336-1\",\"EAC TP TC004 EN/EN61558-1/-2-16\",\"CCC GB4931.1\",\"BSMI\"],\"tran_label\":\"Safety Standard\"},{\"index\":\"7\",\"tran_value\":[\"Input to output:4KVAC Input to ground:2KVAC Output to ground:1.25KVAC\"],\"tran_label\":\"Withstand Voltage\"},{\"index\":\"9\",\"tran_value\":[\"EN55032\",\"EN55014\",\"EN61000-3-2\",\"GB/T9254\",\"BSMI CNS13438\",\"FCC ClassB\"],\"tran_label\":\"EMC Emission\"},{\"index\":\"8\",\"tran_value\":[\"I/P-O/P\",\"I/P-FG\",\"O/P-FG:100m Ohm/500VDC\"],\"tran_label\":\"Insulation Impedance\"}]","type":"2"}
